Does the audio need to be CCC certified?
The 8th category of the CCC product catalog, "Audio and Video Equipment" 0801 sub-category, stipulates that "single-speaker and multi-speaker active speakers with total output power below 500W (effective value)" (ie audio) need to apply for CCC compulsory certification. That is to say, speakers with a total output power of <500W are products within the scope of the 3C certification product catalog and need to be CCC certified.
Audio CCC certification standard
GB8898 "Safety requirements for audio, video and similar electronic equipment"
GB13837 "Sound and television broadcast receivers and related equipment, radio disturbance characteristics, limits and measurement methods"
GB17625.1 "Electromagnetic Compatibility Limit, Harmonic Current Emission Limit (Equipment Input Current ≤16A)"
Information required for audio CCC certification application
1. Circuit schematic diagram;
2. Printed circuit layout and parts location diagram;
3. English manual (the manual must have the manufacturer's name or trademark, model, parameters, installation method and necessary safety warnings);
4. Description of model differences (if there are multiple models in the same series, the similarities and differences between the models must be clearly listed. The statement must be signed);
5. Label/nameplate;
6. Product installation structure diagram/exploded diagram (please specify the number and name of each part);
7. List of key parts and components (the list must be signed);
8. Copies of certificates of important safety-related components.
Audio CCC certification test items
1. Marking and instructions for use;
2. Structural requirements for preventing electric shock;
3. Contact current and electric shock prevention under normal working conditions;
4. Insulation requirements, electric strength;
5. Electrical clearance and creepage distance;
6. Temperature rise and softening point under different combination conditions;
7. Fault setting test, related temperature test, anti-electric shock inspection;
8. Mechanical strength, drop, vibration;
9. Conductor connection terminal and grounding continuity test;
10. Power cord, tensile test;
11. Electrical connection and mechanical fixing;
12. Stability and mechanical hazards, fire prevention;
13. The disturbance voltage injected into the power supply from 9KHz-30MHz;
14. 30-1000MHz disturbance power and harmonic current.
Audio CCC certification process
1. Application for certification
The enterprise submits a product application form to ZRLK, where detailed product information such as product electrical schematic diagram, product manual, product information sheet, etc. must be presented. For specific information, please consult the sales engineer who handles testing and certification for enterprise products.
2. Product testing
The enterprise pays the test deposit, and ZRLK accepts the test application. Enterprises need to provide effective product samples. If the test fails, ZRLK will issue a rectification opinion, and the company will rectify the product until the product meets the CCC certification standards.
3. Factory inspection
The factory is the guarantee of product safety and needs to be kept clean and tidy. CCC factory audit personnel will verify the relevant information of the company, which is mainly divided into information review and quality review.
4. Issuing a certificate
The company has passed the audit and obtained the corresponding CCC certification.
5. Annual factory inspection
CCC certification will conduct a supervision and inspection of the factory once a year. If the inspection fails, the company will be punished accordingly.
